Test Product
This is self supporting FRP Ladder. This is heavy duty fiberglass step ladder for domestic as well as industrial applications. Our standard size Trade FRP ladders are 3step, 5step & 7step..
Ladder | LMT 2103 | LMT 2104 | LMT 2105 | LMT 2106 | LMT 2107 |
---|---|---|---|---|---|
Front Rear Stile : | FRP - Glass Fiber | FRP - Glass Fiber | FRP - Glass Fiber | FRP - Glass Fiber | FRP - Glass Fiber |
Size of FRONT Stile : | 80x28.5x3.0mm | 80x28.5x3.0mm | 80x28.5x3.0mm | 80x28.5x3.0mm | 80x28.5x3.0mm |
Size of REAR Stile : | 38.5x29x3.5mm | 38.5x29x3.5mm | 38.5x29x3.5mm | 38.5x29x3.5mm | 38.5x29x3.5mm |
Steps : | Antiskid Aluminum Alloy | Antiskid Aluminum Alloy | Antiskid Aluminum Alloy | Antiskid Aluminum Alloy | Antiskid Aluminum Alloy |
Size of Steps : | 81x39x1.5mm | 81x39x1.5mm | 81x39x1.5mm | 81x39x1.5mm | 81x39x1.5mm |
Spacing Bet Steps : | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
Closed Up Size(Approx) : | 1117x452x154mm | 1396x497x154mm | 1676x520x154mm | 1956x561x154mm | 2235x589x154mm |
Height of Top(Approx) : | 993mm | 1250mm | 1511mm | 1771mm | 2029mm |
Opening width(Approx) : | 793mm | 973mm | 1146mm | 1328mm | 1499mm |
No. of Steps : | 3 | 4 | 5 | 6 | 7 |
Weight(Approx) : | 5.1kg | 6.1kg | 7.26kg | 8.3kg | 9.4kg |
Max. Load Cap. : | 110kg | 110kg | 110kg | 110kg | 110kg |
- Restrict ladder usage to the purpose for which the ladder is designed. Never exceed the maximum safe working load of the ladder.
- Store in areas protected from direct sunlight. Never use damaged ladder for climbing.
- Self supporting ladder such as trade ladder & platform ladder are not to be used as single ladders, that is , in the closed position.
- Keep both feet on the ladder – never put one foot on a rung/step and the other foot on a different surface.
- A non-self-supporting ladder such as an extension or single ladder, needs to be erected a minimum of one to three feet above the top support point when using for access to a roof or other work level.
- Do not step on any rung above the upper support point since this could cause the ladder to slip.
- Place your ladder on a stable, even, flat surface. Never place a ladder on top of another object.
- On a ladder or step ladder, do not over load it. The person and anything they are taking up should not exceed the highest stand on the ladder.
- On a ladder don’t move them while standing on the rungs/steps.
- Beware of electrical hazards. This is rated electrically isolating for standard utility voltages.
- Do not stand or sit on plastic top cover in trade and platform ladder.
- Always keep a secure grip. Do not use the steps if you feel tired or ill or if you suffer from vertigo or if you have recently taken alcohol.
- Wear firm flat shoes.
- For more information, please refer http://www.hse.gov.uk/pubns/indg402.pdf
